SPECIFICATIONS
Overview
Interface
IDE 44PIN Horizontal
Flash Technology
SLC
Capacity
128MB ~ 1GB
Form Factor
Internal Key / External Key
Dimensions
"48 x 32.6 x 8.7 mm (External Key)
48 x 32.6 x 7.1 mm (Internal Key)"
48 x 32.6 x 7.1 mm (Internal Key)"
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
26 MB/s
Seq. Performance Write (max.)
19MB/s
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
60,000
Operating Environment
Operating Temperature
-40°C～85°C / 0°C～70°C
Storage Temperature
-55°C ～ 95°C
Operating Humidity
"10%～95%
(30°C Max. Wet Bulb Temp)"
(30°C Max. Wet Bulb Temp)"
Vibration
15G, 10 ～ 2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V / DC 3.3V
Power Consumption (max.)
200 mA
Power Consumption (idle)
2 mA
Key Features
S.M.A.R.T
●
Write Protect
◎
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 128MB | 0°C ～ 70°C | SP128MBIFMBFIV201T |
| 128MB | 0°C ～ 70°C | SP128MBIFMBFEV201T |
| 256MB | 0°C ～ 70°C | SP256MBIFMBFIV201T |
| 256MB | 0°C ～ 70°C | SP256MBIFMBFEV201T |
| 512MB | 0°C ～ 70°C | SP512MBIFMBFIV201T |
| 512MB | 0°C ～ 70°C | SP512MBIFMBFEV201T |
| 1GB | 0°C ～ 70°C | SP001GBIFMBFIV201T |
| 1GB | 0°C ～ 70°C | SP001GBIFMBFEV201T |
| 128MB | -40°C～85°C | SP128MBIFMBFIW201T |
| 128MB | -40°C～85°C | SP128MBIFMBFEW201T |
| 256MB | -40°C～85°C | SP256MBIFMBFIW201T |
| 256MB | -40°C～85°C | SP256MBIFMBFEW201T |
| 512MB | -40°C～85°C | SP512MBIFMBFIW201T |
| 512MB | -40°C～85°C | SP512MBIFMBFEW201T |
| 1GB | -40°C～85°C | SP001GBIFMBFIW201T |
| 1GB | -40°C～85°C | SP001GBIFMBFEW201T |
