SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
120GB～1.9TB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
500 MB/s
Random 4K Read (IOPS max.)
55,000
Random 4K Write (IOPS max.)
65,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1.92TB: 3,795TB
960GB: 1,382TB
480GB: 691TB
240GB: 346TB
120GB: 173TB
960GB: 1,382TB
480GB: 691TB
240GB: 346TB
120GB: 173TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)\
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
320 mA
Power Idle / Standby
140 mA
Key Features
Advanced Power Shield
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 120GB | -40 ~ 85℃ | SP120GISSD3M5EW0 |
| 240GB | -40 ~ 85℃ | SP240GISSD3M5EW0 |
| 480GB | -40 ~ 85℃ | SP480GISSD3M5EW0 |
| 960GB | -40 ~ 85℃ | SP960GISSD3M5EW0 |
| 1.9TB | -40 ~ 85℃ | SP019TISSD3M5EW0 |
