SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
120GB～1.9TB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
500 MB/s
Random 4K Read (IOPS max.)
55,000
Random 4K Write (IOPS max.)
65,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1.92TB: 3,795TB
960GB: 1,382TB
480GB: 691TB
240GB: 346TB
120GB: 173TB
960GB: 1,382TB
480GB: 691TB
240GB: 346TB
120GB: 173TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G (Peak-to-Peak), 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
320 mA
Power Idle / Standby
140 mA
Key Features
Power Failure Protection (PFP)
●
Advanced Power Shield
●
AES-256
●
Thermal Throttling
●
DEVSLP
◎
S.M.A.R.T
●
DAP
●
FWxpress
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 120GB | -40 ~ 85℃ | SP120GISSD3M5RW0 |
| 240GB | -40 ~ 85℃ | SP240GISSD3M5RW0 |
| 480GB | -40 ~ 85℃ | SP480GISSD3M5RW0 |
| 960GB | -40 ~ 85℃ | SP960GISSD3M5RW0 |
| 1.9TB | -40 ~ 85℃ | SP019TISSD3M5RW0 |
